Drivetrain
| Transmission | |
| Gearbox | 6-speed |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission Type | Chain (final drive) |
Suspension
| Front Suspension | Telescopic fork |
| Rear Suspension | Twin shocks |
| Front Travel | 10.6 in (268 mm) |
| Rear Travel | 10 in (254 mm) |
Brakes
| Front Braking System | Single disc. Single disc with twin-piston caliper. Optional ABS. |
| Rear Braking System | Single disc. Single disc with single-piston caliper. Optional ABS. |
Tires
| Front Tire | 130/80-B17 |
| Rear Tire | 180/65-B16 |
| Wheels | Impeller Cast Aluminum |
Dimensions
| Overall Vehicle Size | 32.5" w x 49.8" h |
| Rake / Trail | 26° / 7" |
| Wheelbase | 64 in (1,625 mm) |
| Seat Height | 28.9 in |
| Ground Clearance | 5.3 in (135 mm) |
Capacities
| Seating Capacity | 0 |
| Fuel Capacity | 6 gal (22.7 L) |
| Hitch Type | Rear: Receiver |
Weights
| Dry Weight | 388 lbs |
Lights & Safety
| Instrumentation | Larger speedometer and tachometer with wide numbers large fuel and volt gauges with wide numbers display features odometer, trip A, trip B, range to empty, clock and gear indicator and larger telltale indicators |
| Warranty | 12 Month Limited Warranty |
| Lighting | High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory,security system (optional), 6-speed, low fuel warning, ABS (optional) |
What type of fuel does a 2020 Harley-Davidson Softail Fat Bob 114 use?
A 2020 Harley-Davidson Softail Fat Bob 114 uses Gasoline.
What engine does the 2020 Harley-Davidson Softail Fat Bob 114 have?
The 2020 Harley-Davidson Softail Fat Bob 114 is equipped with a 1868cc 4-stroke V2 engine.
What type of engine does the 2020 Harley-Davidson Softail Fat Bob 114 have?
The 2020 Harley-Davidson Softail Fat Bob 114 is equipped with a 4-stroke engine.
